optris CompactPlus Connect User Manual

CSvision 99-
4.3. Sensor Setup CSvision – Output
4.3.1. Output 1 and 2
The device has two outputs (OUT 1, OUT 2) which can be configured
as desired. The following options are available under Mode:
• Off
• Analog
• Alarm
Bei Aktivierung von Analog stehen im Feld Quelle folgende Signalquellen zur Wahl:
▪ TProc
Process temperature
▪ TRatio
Ratio temperature
▪ T1
1 channel temperature
▪ T2
2 channel temperature
▪ Attenuation
Signal attenuation in %
▪ TDet
Temperature of detector
▪ TBox
Sensor temperature
