CSvision 95-
Regression accuracy: Characteristic value to evaluate the description of the measured values by the
polynomial. Larger values are better. A value of 1 means perfect agreement. The regression accuracy is
calculated automatically.
Average slope: The mean value of all slopes is calculated (violet straight line in the right diagram). The default
setting is Auto. Alternatively it can be set manually. Allows to manually move the average slope (display
optimization).
The following settings can be made in the menu under
Apply.
Apply Smart Ratio with new data: The created regression
curve is written to the device and the Smart Ratio mode is
activated. A message window appears indicating that the
table is being saved to the device.
Apply Smart Ratio with old data: Regression curve already stored in the device is retained and Smart Ratio
mode is activated.
Apply average slope: Set average slope and activate standard ratio mode.
Apply old slope: Restore the slope value before opening the Smart Ratio configuration.
4.2.3. Post Processing
In the category Post Processing you can select the Source and make following settings:
To Next Page
