The device has two outputs (OUT-1, OUT-2) which
can be configured as desired. The following options
are available for selection:
• Off
• Analog mA
• Analog mV
• Alarm mA
• Alarm mV
• TCK
When using the analog mA or mV output, either T
Proc
,
T
Int
or T
Box
can be selected as source. The desired
temperature measurement range of the sensor can
now be set. The range limits can be changed by
entering the values in the corresponding fields.
▪ TMin: lower temperature range limit
▪ TMax: upper temperature range limit
▪ Min [mA/mV]: lower limit mA/mV output
▪ Max [mA/mV]: upper limit mA/mV output
