Install Disk Midplane Module
Chapter5 • Servicing FRUs 113
e.
Lift the disk midplane module up and out of the system [4].
f.
Place the board on an antistatic mat.
Install Disk Midplane Module
1.
Install the disk midplane module.
a.
Move the front indicator module (FIM) cable connectors toward the rear of
the system so that the disk midplane module is not installed over them.
b.
Lower the disk midplane module in the system chassis [1].
c.
Position the disk midplane module against the disk drive cage, tilting the top
slightly forward so that it fits over the top-most standoff on the left side and
then position board so that it fits over the remaining 12 standoffs, then push
downward on the board to engage the standoffs [2].
d.
To secure the disk midplane module to the disk drive cage, install the
Phillips screw [3].
e.
Reconnect the two FIM cable connectors to the receptacles on the disk
midplane module [4].
