Install the CMA
6.
Insert the left CMA slide rail connector into the left slide rail assembly until the
connector locks into place with an audible click.
No. Description
1 CMA slide rail connector
2 Left slide rail
7.
Install and route cables to your server, as required.
Note - Instructions for installing the server cables are provided in “Connecting the Server
Cables” on page 41.
8.
If required, attach the cable hooks and loop straps to the CMA, and press the
hooks and straps into place to secure the cables.
Installing the Server 37
