Install the CMA
Note - Cable hooks and loop straps are preinstalled on the CMA. Perform the procedure in this
step if you need to reinstall cable hooks and straps on the CMA.
For best results, place three cable straps, evenly spaced, on the rear-facing side of the CMA, and
three cable straps on the side of the CMA nearest the server.
No. Description
1 CMA cable strap
2 CMA arm
Related Information
■
“Verify Operation of Slide Rails and CMA” on page 39
■
“Secure Cables to the CMA” on page 52
38 SPARC T7-2 Server Installation Guide • March 2016
