Ormazabal ekor.rps User Manual

IG-150-EN version 04; 03/10/16
117
General instructions
ekor.rps
Automation functions
5.3. Reclosing after tripping by minimum frequency
5.3.1. General description
After a trip by minimum frequency, if the function is enabled
and not locked, the unit tries only one reclosing.
When the unit trips, the recloser moves onto ongoing cycle
and waits the programmed closing time; in that moment,
if the minimum frequency condition is set as “NO” or if the
frequency is higher than the minimum programmed, the
close command is given to the breaker. If the minimum
frequency condition is set as “YES” and it is not fullled, it
moves to denitive trip.
The signal 79 f-switch/circuit breaker closing blocking is
active until the reclosing or denitive tripping conditions
are met.
If the “denitive tripping waiting time” has elapsed and the
reclosing conditions have not been met, it goes to denitive
tripping if “denitive tripping waiting time” is set to “YES”. If
it is set to “NO”, it remains waiting for reclosing conditions
indenitely.
There is a reclaim time after the closure, if during that time
a new trip by minimum frequency happens, it moves to
denitive trip.
Setting the recloser out of service by command or by
locking by digital input aects both this operating mode
and the trip by current operating mode.
5.3.2. Settings
Setting Min Max Step Notes
Enable
YES/NO
Min. freq. Condition to reclose
YES/NO
Min. frequency to reclose
40 70 0.01
Closing time [s]
1 1000 1
Reclaim time [s]
1 300 1
Enable denitive tripping waiting time
YES/NO
Denitive tripping waiting time [s]
0 86 400 1
Reclosing condition Min. Voltage
YES/NO
Reclosing value Min. Voltage. [V]
0 200 0.1
Table 5.2. Settings
Note: This type of operation is used from version “AD” of the CPU’s FW.
