Ormazabal ekor.rps - Connection between Fiber Optic and a Radio Modem

IG-150-EN version 04; 03/10/16
39
General instructions
ekor.rps
Hardware
2.6. Connection between fiber optic and a radio modem
The contact of the ekor.rps protection is made by
programming a digital output such as “RTS control”.
12 3
4
5
1
ekor.rps
2
FO/RS232 converter
3
Radio
4
RTS (contact)
5
+12 V
dc
(aprox)
Figure 2.11. Connection between ber optic
