IG-150-EN version 04; 03/10/16
53
General instructions
ekor.rps
Unit configuration
3.6.7. Push-buttons/LEDs enabling and locking by command
Under the title “PUSH-BUTTONS” there are two settings:
“ENAB. PUSH-BUTTON” (enable push-buttons): If this setting
is at “COMMAND”, the front plate command push-buttons
are enabled; if it is set at “NO”, it is as if they did not exist.
If it is at “FUNCTIONALS” both the command push-buttons
and the keys can be used to order commands. These push-
buttons are only eective when the equipment is in local
mode. The equipment starts in remote. To change to local
mode, press “L/R” and “.” if it is in COMMAND and “L/R” if it is
in FUNCTIONALS. The order “local mode” or “remote mode”
must be programmed in the command associated to that
push-button (“Command conguration” screen), in the ON
and OFF positions. The equipment changes then to local
mode and the functional push-buttons are enabled.
“ENAB.COMMAND LOC” (Enable blocking/unblocking by
command): If this setting is at “YES”, the programmed
protection function blocking/unblocking control commands
are enabled; if it is set at “NO”, they are disabled.
“R KEY BLOCKING”. If it is set to “YES”, the Leds are not
handled in the program, they are all deactivated except for
Led 8, which turns green.
There is a setting under “PRESS REMOTE” which allows to
execute commands via push-buttons if it is set to “YES”,
even in “remote” mode. If it is set to “NO”, it must be in “Local”
mode to execute the commands.
3.6.8. Power supply supervision enabling
The power supply supervision can be enabled or not. For its
operation, see section “Power supply supervision”.
3.6.9. Power supply enabling
Only in those models with the option “battery voltage
measurement”. The power supply supervision can be
enabled or not. See “Power supply supervision” section for
its operation.
3.6.10. Display contrast setting
The procedure to follow is the following one:
1. By pushing key “
” (in a 16-key keyboard) for 3 to 5
seconds, you can enter the contrast setting menu and
there will appear the text “contrast setting. - DOWN +
U P ”.
2. With keys “
↑ and ↓“ the contrast is set. With “↑“ more
bright is given and with “↓ “ it is darkened.
In order to validate, push “ESC” or after 1 minute it goes back
to its normal situation, with the changes already carried out.
