Page #126 background imageLoading...
Page #126 background image
IG-150-EN version 04; 03/10/16
126
data acquisition functions General instructions
ekor.rps
7.3.2. Measurements at the primary
By keyboard/display
Phase A current (in amperes)
1. Phase B current " "
2. Phase C current " "
3. Neutral current " "
4. Phase A simple voltage (in kV)
5. Phase B simple voltage ( " " )
6. Phase C simple voltage ( " " )
7. Average simple voltage ( " " )
8. Compound voltage V
AB
(in kV)
9. Compound voltage V
BC
( " " )
10. Compound voltage V
CA
( " " )
11. Average compound voltage ( " " )
12. Neutral voltage
13. Active total power [MW]
14. Reactive total power [MVAr]
15. Apparent total power [MVA]
16. Active power by phase (only valid if the simple voltages
are connected)
17. Reactive power by phase (only valid if the simple
voltages are connected)
18. Power factor
19. Active energy counter (positive)
20. Active energy counter (negative)
21. Reactive energy counter (positive)
22. Reactive energy counter (negative)
23. Date and time of the counter setting to 0
24. Frequency (in Hz)
25. Current maximeter (in A)
26. Total power maximeter
27. Power by phase maximeter (only valid if the simple
voltages are connected)
28. Harmonics distortion factor in I
A
,I
B
andI
C
(in%)
29. Harmonics distortion factor in V
A
,V
B
andV
C
(in%)
30. The harmonic distortion factors are given as the ratio
between the fundamental and the result of considering
the harmonics 1 to 15
The phase current values in this screen are
absolute values, this is without the sign.
Through PC (protections console)
1. They are on the rst of the "measurements" screens
2. Phase A current (module in amperes and angle in
degrees)
3. Phase B current
4. Phase C current
5. Neutral current
6. Neutral sensitive current
7. Current maximeter (in A)
8. Date and time corresponding to the maximeter
9. Phase A simple voltage (module in kV and angle in
degrees)
10. Phase B simple voltage
11. Phase C simple voltage
12. Compound voltage V
AB
(in kV)
13. Compound voltage V
BC
( “ )
14. Compound voltage V
CA
( “ )
15. Average compound voltage ( “ )
16. Frequency
17. Active total power [MW]
18. Reactive total power [MVAr]
19. Apparent total power [MVA]
20. Active power by phase (only valid if the simple voltages
are connected)
21. Reactive power by phase (only valid if the simple
voltages are connected)
22. Average power factor
23. Power factor by phase (only valid if the simple voltages
are connected)
24. Active energy counter (positive)
25. Active energy counter (negative)
26. Reactive energy counter (positive)
27. Reactive energy counter (negative)
28. Date and time of the counter setting to 0
29. Harmonics distortion factor in I
A
, I
B
and I
C
(in%)
30. Harmonics distortion factor in V
A
, V
B
and V
C
(in%)
31. The harmonic distortion factors are given as the ratio
between the fundamental and the result of considering
the harmonics 1 to 15
The phase current values in this screen are
absolute values, this is without the sign.
