Ormazabal ekor.rps User Manual

IG-150-EN version 04; 03/10/16
141
General instructions
ekor.rps
Reception, storage, installation and tests
10. Reception, storage, installation and tests
10.1. Reception and storage
The protections are supplied in special packing material for
transport.
Upon reception, they should be checked for any signs of
external damage caused during transport; if so the transport
rm and manufacturer should be contacted.
The material received should also be checked to see if it
coincides with the order number.
If the protection is not going to be used immediately, it
should be stored in its original packaging and in a dry and
dirt free place.
The units transport must be made in its original packaging.
10.2. Connecting procedure
The protection connecting procedure should be carried
out in accordance with the enclosed external connection
diagram. It is a general diagram; the programming of inputs
and outputs should be taken into consideration in each
specic case.
10.2.1. Power supply
The polarity is indierent.
10.2.2. Earth connection
It is important for the earth connection to be correctly
connected, in order for the protection disturbance rejection
devices it incorporates to operate properly. The connection
should be as short as possible (less than 25 cm) using
multiwired cable with a 4 mm
2
cross-section.
10.2.3. RS232 cable connections to be used between the PC and the ekor.rps unit
Case 1: A 25 pin PC output connector.
ekor.rps side PC side
male 9 pin socket
female 25 pin socke
t
RxD
2 2 TxD
T
xD 3 3 RxD
GND
5 7 GND
DSR
6 20 DTR
RTS
7 8 CD
CTS
8 5 CTS
CD
1 4 RTS
DTR 4 6 DSR
Case 2: A 9 pin PC output connector.
ekor.rps side PC side
male 9 pin socket female 9 pin socket
RxD
2 3 TxD
T
xD 3 2 RxD
GND
5 5 GND
DSR
6 4 DTR
RTS
7 CD
CTS
8 8 CTS
CD
1 7 RTS
DTR 4 6 DSR
