IG-150-EN version 04; 03/10/16
12
General description General instructions
ekor.rps
1.6. Environmental conditions
1. Operating temperature: -10 up to 55 °C
2. Storage temperature: -40 up to 85 °C
3. Relative humidity: Up to 95 % without condensation
1.7. Tests
1.7.1. Electrical tests
1. Measurement of dielectric rigidity: Acc. to/IEC 255-5,
series C (2 kV, 1 min)
2. Measurement of insulation resistance: Acc. to/IEC255-5,
>10GΩ at 500 V
dc
3. Pulse (shock wave): Acc. to/IEC 255-5, appendix E, classIII
4. HF disturbances: Acc. to/IEC 255-22-1, class III
5. Fast transients: Acc. to/IEC 61000-4-4, class IV
6. Immunity to electrostatic discharges: Acc. to/IEC61000-4-2,
class IV
7. Voltage pulses: Acc. to/IEC 61000-4-5, class IV
8. Micro-cuts: Acc. to/IEC 60255-11, 100ms a 125V
dc
9. Radiated electromagnetic interference:
Acc. to/EN 61000-6-4
10. Immunity to radiated elds: Acc. to/IEC 61000-4-3,
class III
11. Immunity to conducted: Acc. to/IEC 61000-4-6, class III
radiofrequency signals
12. Immunity to low frequency: Acc. to/IEC 61000-4-8
radiated elds
1.7.2. Environmental tests
1. Cold: Acc. to/IEC 68-2-1 (-40 °C)
2. Dry heat: Acc. to/IEC 68-2-2 (+85 °C)
3. Humid heat: Acc. to/IEC 68-2-3 (+70 °C, 93 % relative
humidity)
4. Change of temperature: Acc. to/IEC 68-2-14 (-20°/70°C
two 4-hour cycles)
5. Operating range: -10 °C. up to 55 °C
1.7.3. Mechanical tests
1. Vibration test: Acc. to/IEC 255-21-1 class II 2. Shock and bump test: Acc. to/IEC 255-21-1 class I
1.8. CE Conformity
This product complies with the European Union directive
2014/30/EU on electromagnetic compatibility, and with
the IEC 60255 international regulations. The unit has been
designed and manufactured for use in industrial areas,
in accordance with EMC standards. This conformity is a
result of the test carried out in accordance with article 7 of
the Directive.
