Osstem Implant K3 - Page 12

12
Ⅲ K3 UNIT CHAIR Installation
CHAIR INSTALLATION
§ Installation procedures #3
5. Install backrest bracket
As shown in <Figure 05>, assemble the
backrest bracket (D) to the backrest
support ①.
6. Install backrest seat
As shown in <Figure 06>, assemble the
backrest seat (E) to the backrest bracket
(D).
Use a Phillips screwdriver
Use a Phillips screwdriver
1
< Figure 05 >
< Figure 06 >
『CHAIR Installation』
