Ⅲ K3 UNIT CHAIR Installation
CHAIR INSTALLATION
§ Installation procedures #6
11. Remove the main power cable
As shown <Figure 11>, remove the main
power cable located in the chair assembly.
12. Assemble power switch
As shown in <Figure 12>, plug the main
power switch into the base back cover (I)
and mount it on the base plate.
< Figure 11 >
< Figure 12 >
『CHAIR Installation』
