16
Ⅲ K3 UNIT CHAIR Installation
CHAIR INSTALLATION
§ Installation procedures #7
13. Assemble main power cable
As shown in <Figure 13>, connect the
connector.
14. Assemble power switch
As shown in <Figure 14>, place the base
front cover (J) on the base plate and fasten
with bolts on both sides.
< Figure 13 >
< Figure 14 >
Use a Phillips screwdriver
『CHAIR Installation』
