Ⅲ K3 UNIT CHAIR Installation
DOCTOR TABLE INSTALLATION
§ Installation procedures #3
5. Assemble Sub Table
As shown in <Figure 05>, fasten Sub Table (E) to
Sub Table Bar (F) with bolts.
6. Install Sub Table Assembly
As shown <Figure 06>. fasten Sub Table Bar (F) to
Lower Table Block (G) with bolts.
< Figure 06 >
< Figure 05 >
Use a Phillips screwdriver
Use a Phillips screwdriver
『TABLE Installation』
