OTC DTX-3000 AC/DC - Page 33

Operation
33
DTX-2200-3000 AC/DC
2200 AC/DC 3000 AC/DC
TIG AC
COLD TIG
16 - 127 A 5 - 173 A
2200 AC/DC 3000 AC/DC
TIG AC
SPEED TIG
5 - 220 A 5 - 300 A
L25 COLD TIG
Triangular wave: low heat generation with reduced distortion, ideal for minor thicknesses.
W ARNING:
LED L25 switched on and flashing.
The
display shows the “RMS” current value for p re-set - ting and welding.
L26 SOFT TIG
Sinusoidal wave: ensures a gentle, soft arc with limited noise, ideal for average thicknesses and butt welding.
W
ARNING:
LED L26 switched on and steady.
The
display shows the “RMS” current value for p re-set - ting and welding.
2200 AC/DC 3000 AC/DC
TIG AC
SOFT TIG
16 - 156 A 5 - 212 A
