Operation
42
DTX-2200-3000 AC/DC
14.3.9
TIG-welding – Welding parameters
The DTX HF can be configured in the following 2 ways:
• STANDARD (Std) configuration.
• SPECIAL (SPE) configuration.
14.3.9.1 STANDARD CONFIGURATION (Std)
When it leaves the factory the welding machine is normally configured in STANDARD (Std) mode.
To check the configuration, carry out the following operations:
1) When the welding machine is off, push and hold the “PRG” PROGRAM key down (T2).
2) Start the welding machine by turning the power supply switch to position I.
3) The DISPLAY (D) shows the following message: Std (welder configured in STANDARD mode).
4) Press the “PRG” PROGRAM key (T2) to confirm.
The WELDING PARAMETERS included, programmable, and that can be edited (by turning the ENCODER key)
in a STANDARD (Std) configuration can be broken down into 3 different sub-groups:
1. “BASIC” WELDING PARAMETERS
Press the WELDING PARAMETERS SELECTION key (T10) a number of times to set:
L12 PRE-GAS duration (0,05 - 1,00 sec)
WARNIG: With a TIG-welding process with active "Lift" ignition the function is not programmable.
