Configuration
Mainframe [AV-HS450U1E] .............................................................................. 1
Control panel [AV-HS450C1E] .......................................................................... 1
Accessories
Operating instructions ....................................................................................... 1
CD-ROM (Operating instructions/Image transmission software) ...................... 1
AC adapters (for control panel) ......................................................................... 2
Power cords (for mainframe and AC adapter) .................................................. 8
CAT5E cable (STP, straight cable, 10 m long) .................................................. 1
Option boards (sold separately)
Board Model number Function
SDI Input Board AV-HS04M1
SDI input 2 lines
Analogue Input Board AV-HS04M2
Analogue component input 2 lines
DVI Input Board AV-HS04M3
DVI-I input 2 lines
Analogue Output Board AV-HS04M4
Analogue component output 2 lines
DVI/Analogue Output Board AV-HS04M5
DVI-I output 1 line
Analogue component output 1 line
Analogue Composite Input Board AV-HS04M6
Analogue composite input 2 lines
SDI Output Board AV-HS04M7
SDI output 2 lines
Full-HD DVI Input Board AV-HS04M8
DVI-D input 2 lines
Option boards are installed in the two input/output option slots (slot A, slot B).
