3. Basic operations
3-4-2. Selecting the key material
Selecting the key fill signal
Press the [KEY] button among the AUX bus selector buttons to light its indicator, and press one of the AUX bus
crosspoint buttons (1 to 32) to select the key fill signal.
Selecting the key source signal
Set the key source for key fill.
This setting is the same for KEY and DSK.
Setting with AUX bus crosspoint buttons

Press the [KEY] button (or [DSK 1/2] buttons) of the AUX bus selector buttons to light its indicator, and hold
down the AUX bus crosspoint button for the selected key fill signal.
<Menu display>
XPTStats
|
FILL: INPUT1 SRC↓ INPUT1
| XPT : 1

Turn the [F5] and select a key source signal (SRC) for the key fill signal (FILL), and press the [F5] switch.
Setting in the CONFIG menu

Press the [CONFIG] button to light its indicator, and display the CONFIG menu.
 Refer to “2-1-5. LCD menu area”.

Turn [F1] to display the KSAsign sub menu.
<Menu display>
CONFIG11
|
Fill
|
Source↓
| |
KSAsign | —| —| |
IN1-16
IN-A1
IN-A2
IN-B1
IN-B2
CBGD
CBAR
FMEM1-4
IN1-16
IN-A1
IN-A2
IN-B1
IN-B2
CBGD
CBAR
FMEM1-4
NoAsign

Turn [F2] to select the key fill material using the Fill item.

Turn [F3] to select the key source material using the Source item, and press the [F3] switch.
The luminance and chroma keys are used as self keys so the key fill signal can be used as the key source
signal regardless of the menu setting.
