10. Specifications
Mainframe [AV-HS450U1E]
Video inputs
(20 signal lines,
maximum)
Standard SDI: 16 signal lines (IN1 to IN16)
BNC 16
Optional: Up to 4 additional signal lines (IN A1, IN A2, IN B1, IN B2)
(Up to two option boards can be installed in the two input/output slots.)
Video outputs
(10 signal lines,
maximum)
Standard SDI: 4 signal lines (OUT1 to OUT4 1 line each,
2 distributed outputs for OUT1 only)
BNC 5
Standard DVI-D: 2 signal lines (OUT5, OUT6)
DVI-D 2
Optional: Up to 4 additional lines (OUT A1, OUT A2, OUT B1, OUT B2)
(Up to two option boards can be installed in the two input/output slots.)
 PGM, PVW, AUX1 to AUX4, MV1 (MULTI_PVW1), MV2 (MULTI_PVW2), CLN and
KEYOUT can be allocated to each output.
 CLN can be pre-selected from KEY, DSK1 or DSK2 using a menu.
Signal formats SD 480/59.94i, 576/50i
HD
1080/59.94i, 1080/50i, 720/59.94p, 720/50p, 1080/24PsF

, 1080/23.98PsF

: The following option boards are not supported:
AV-HS04M1, AV-HS04M2, AV-HS04M3, AV-HS04M4, AV-HS04M5,
AV-HS04M6, AV-HS04M7
Signal processing Y:Cb:Cr 4: 2: 2, 10 bit (8 bits for frame memory)
RGB 4:4:4, 8 bit
ME number 1ME
SDI inputs HD: Serial digital component (SMPTE 292M)
SD: Serial digital component (SMPTE 259M)
16 signal lines, standard: IN1 to IN16
20 signal lines, maximum: IN A1, IN A2, IN B1, IN B2
(When two AV-HS04M1 boards are used; with active through)
HD [SMPTE 292M (BTA S-004B) standard complied with]
• 0.8 Vp-p 10 % (75 )
• Input return loss More than 15 dB (5 MHz to 750 MHz)
More than 10 dB (750 MHz to 1.5 GHz)
• Automatic equalizer 100 m (when 5C-FB cable is used)
SD [SMPTE 259M standard complied with]
• 0.8 Vp-p 10 % (75 )
• Input return loss More than 15 dB (5 MHz to 270 MHz)
• Automatic equalizer 200 m (when 5C-2V cable is used)
