5. System settings
5-7-2. Editor control
The following lists the functions which can be controlled by editing controller AG-A850.
(Compliant with the GVG protocol)
• Read command
• Crosspoint switch
• Wipe pattern selection (BKGD)
• Transition mode (MIX/WIPE) selection
• Auto transition time setting
• Auto transition execution
<Table of wipe patterns supported>
GVG
protocol
AV-HS450E
GVG
protocol
AV-HS450E
GVG
protocol
AV-HS450E
GVG
protocol
AV-HS450E
1 WIPE No.1 22 SQ1 No.10 43 3D1 No.7 64 SL2 No.4
2 WIPE No.2 23 — 44 3D1 No.8 65 —
3 WIPE No.3 24 SQ1 No.12 45 3D1 No.9 66 SL2 No.6
4 WIPE No.4 25 SL1 No.1 46 3D1 No.10 67 —
5 WIPE No.5 26 SL1 No.2 47 3D1 No.11 68 SL2 No.8
6 WIPE No.6 27 SL1 No.3 48 3D1 No.12 69 —
7 WIPE No.7 28 SL1 No.4 49 — 70 —
8 WIPE No.8 29 SL1 No.5 50 SQ2 No.2 71 —
9 WIPE No.9 30 SL1 No.6 51 — 72 —
10 WIPE No.10 31 SL1 No.7 52 SQ2 No.4 73 —
11 WIPE No.11 32 SL1 No.8 53 — 74 SD2 No.2
12 WIPE No.12 33 SL1 No.9 54 SQ2 No.6 75 —
13 SQ1 No.1 34 — 55 — 76 SD2 No.4
14 SQ1 No.2 35 — 56 SQ2 No.8 77 —
15 SQ1 No.3 36 — 57 — 78 SD2 No.6
16 SQ1 No.4 37 3D1 No.1 58 — 79 —
17 SQ1 No.5 38 3D1 No.2 59 — 80 SD2 No.8
18 SQ1 No.6 39 3D1 No.3 60 — 81 —
19 SQ1 No.7 40 3D1 No.4 61 — 82 —
20 SQ1 No.8 41 3D1 No.5 62 SL2 No.2 83 —
21 SQ1 No.9 42 3D1 No.6 63 — 84 —
On the RS422 sub menu of the CTL menu, set On or Off for control from the external device (editor) connected to
the EDITOR connector.
For details on the settings, see “5-7-1. Enable/disable setting for control of external devices”.
