3. Basic operations
3-9-3. Setting enable/disable for the AUX1 transition
The AUX1 transition time and transition enable/disable can be set.

Press the [TIME] button to light its indicator and display the TIME menu.
 Refer to “2-1-5. LCD menu area”.

Turn [F1] to display the AUX1 sub menu.

Turn [F4] to select the display unit using the Unit item.

If frame has been selected as the unit, turn [F2] or [F3] to set the length of the transition time.

If second (sec) has been selected as the unit, turn [F2] to set the second unit or turn [F3] to set the frame
unit.
<Menu display>
TIME 7
|
TransTime
|
Unit
|
ENBL
AUX1 | 16s| 39f| Sec| Enable
TIME 7
|
TransTime
|
Unit
|
ENBL
AUX1 | 999f| Frame| Enable
Disable
Any time in the range from 0 to 999f can be set. Depending on the video format, the time that can be set
with a display in seconds will differ.
59.94i: max. 33s09f, 59.94p: max. 16s39f, 50i: max. 39s24f, 50p: max. 19s49f,
24psf: max. 41s15f, 23.98psf: max. 41s15f

Turn [F5] to set enable or disable for the transition using the ENBL item.
Enable: Enable
Disable: Disable
When disable has been set for the transition, the output signals are switched with no transition when the
output signals set in AUX1 is switched.
