4. Input/output signal settings
4-2-2. Adjusting the DVI input signals
Adjust the clock/phase and position of the DVI-I input signals.

Press the [INPUT] button to light its indicator and display the INPUT menu.
 Refer to “2-1-5. LCD menu area”.

Turn [F1] to display the INPUT XX sub menu.
(X: A1, A2, B1 or B2)
The input used to set the clock phase and position is selected for X.

Turn [F2] to display the third menu of DVIPhs.
<Menu display>
INPUT XX
|
DVIPhs
|
ClkPhs
|
H-Pos
|
V-Pos
| 4/4 | 0| 0| 0
−16
|
15
−100
|
100
−100
|
100

Turn [F3] to adjust the clock phase of the analogue input signals using the ClkPhs item.
While viewing the image quality, set the value at which the noise level is minimized.

Turn [F4] to adjust the horizontal position using the H-Pos item.

Turn [F5] to adjust the vertical position using the V-Pos item.
