Control signals are comprised mainly of 8-bit identification signals and the data signals added to
them. Data signals are added to DIS and DCS signals.
Signal.....DIS (Digital Identification Signal)
Identification Signal Format.....00000001
Function:
Notifies the capacity of the receiving unit. The added data signals are as follows.
Signal.....DCS (Digital Command Signal)
Identification Signal Format.....X1000001
Example (Some models do not support the following items.):
Bit No. DIS/DTC DCS
1 Transmitter --- T.2 operation
2 Receiver --- T.2 operation Receiver --- T.2 operation
3 T.2 IOC = 176 T.2 IOC = 176
4 Transmitter --- T.3 operation
5 Receiver --- T.3 operation Receiver --- T.3 operation
6 Reserved for future T.3 operation features
7 Reserved for future T.3 operation features.
8 Reserved for future T.3 operation features.
9 Transmitter --- T.4 operation
10 Receiver --- T.4 operation Receiver --- T.4 operation
11, 12, 13, 14
0, 0, 0, 0
0, 1, 0, 0
1, 0, 0, 0
1, 1, 0, 0
0, 0, 1, 0
0, 1, 1, 0
1, 0, 1, 0
1, 1, 1, 0
0, 0, 0, 1
0, 1, 0, 1
1, 0, 0, 1
1, 1, 0, 1
0, 0, 1, 1
0, 1, 1, 1
1, 0, 1, 1
1, 1, 1, 1
Data signaling rate
V.27 ter fall back mode
V.27 ter
V.29
V.27 ter and V.29
Not used
Reserved
Not used
V.27 ter and V.29 and V.33
Not used
Reserved
Notused
V.27 ter and V.29 and V.33 and V.17
Not used
Reserved
Not used
Reserved
Data signaling rate
2400 bit/s, V.27 ter
4800 bit/s, V.27 ter
9600 bit/s, V.29
7200 bit/s, V.29
14400 bit/s, V.33
12000 bit/s,V.33
Reserved
Reserved
14400 bit/s, V.17
12000 bit/s, V.17
9600 bit/s, V.17
7200 bit/s, V.17
Reserved
Reserved
Reserved
Reserved
15 R8×7.7 lines/mm and/or 200×200 pels/
25.4mm
R8×7.7 lines/mm and/or 200×200
pels
25.4mm
16 Two-dimensional coding capability Two-dimensional coding
capability
