Panasonic KX-FP342CX

Ref. No. Part No. Part Name & Description Remarks
C308 ECUV1H331JCV 330P S
C309 ECUV1H331JCV 330P S
C310 ECUV1C104KBV 0.1 S
C311 ECUV1C104KBV 0.1 S
C314 ECUV1C104KBV 0.1 S
C316 ECUV1H103KBV 0.01 S
C317 ECUV1H103KBV 0.01 S
12.5. POWER SUPPLY BOARD PARTS
Ref. No. Part No. Part Name & Description Remarks
PCB4 N0AZ2GF00001 POWER SUPPLY BOARD ASS'Y (RTL)
(ICs)
IC101 PFVIFA5317P IC
IC201 AN1431T IC
IC202 AN7805F IC
(TRANSISTOR)
Q101 2SK2651 TRANSISTOR(SI)
(DIODES)
D101 PFVD1N4005 DIODE(SI)
S
D102 PFVD1N4005 DIODE(SI)
S
D103 PFVD1N4005 DIODE(SI)
S
D104 PFVD1N4005 DIODE(SI)
S
D105 PFVDEG01C DIODE(SI) S
D106 MA165 DIODE(SI)
D107 MA4220 DIODE(SI)
D108 PQVDERA1802 DIODE(SI) S
D201 PFVDSF5LC20U DIODE(SI) S
D202 PFVD11DQ10 DIODE(SI) S
(COIL)
L101 ELF15N005A COIL
(COMPONENT PART)
L103 EXCELDR35 COMPONENT PART
(CONNECTORS)
CN301 PQJP7G30Z CONNECTOR,7PIN
CN31 PQJP2D98Z CONNECTOR,2PIN
(FUSE)
F101 PQBA2C31TRLW FUSE
S
(PHOTO ELECTRIC TRANSDUCER)
PC101 PFVIPC123 PHOTO COUPLER
S
224
