Panasonic KX-FP342CX User Manual

key High Frequency
(Hz)
key Low Frequency
(Hz)
“1” 697 “5” 1209
“2” 770 “6” 1336
“3” 852 “7” 1477
“4” 941 “8” 1633
When set to OFF (=2), the 12 keys and transmission frequencies are as shown.
High (Hz) 1209 1336 1477
Low (Hz)
697 “1” “2” “3”
770 “4” “5” “6”
852 “7” “8” “9”
941 “ ” “0” “#”
Note:
After performing this check, do not forget to turn the setting off.
Otherwise, dialing in DTMF signal will not work.
6.3.2. BUTTON CODE TABLE
Code Button Name Code Button Name Code Button Name Code
Button
04 FAX /START / SET 31 1 3C # 64
STATION
05 LOWER 32 2 3D REDIAL PAUSE 65
STATION
06 COPY 33 3 3E FLASH 66
STATION
08 MONITOR 34 4 47 SEARCH 67
STATION
0A MUTE 35 5 4E JUNK FAX
PROHIBITOR
68
STATION
0C RECEIVE MODE 36 6 1E
NEXT
20 MENU 37 7 1F
PREV
22 HELP 38 8
25 [+] VOLUME 39 9 00 NO INPUT
26 [-] VOLUME 3A 0 01 STOP
3B
6.3.3. PRINT TEST PATTERN
1. Platen roller
71
