Panasonic KX-FP342CX

Ref. No. Part No. Part Name & Description Remarks
C123 ECUV1H561JCV 560p
C124 ECUV1E104KBV 0.1 S
C201 PFCEA35F471 470 S
C202 ECKN3A102KBP 0.001
C203 PFCEA16B470 47 S
C204 PFCEA35A47M 47 S
C205 PFCEA50A1M 1 S
C206 ECKN3A102KBP 0.001
C221 ECUV1E104KBV 0.1
C222 ECUV1H104ZFV 0.1
12.6. SENSOR BOARD PARTS
Ref. No. Part No. Part Name & Description Remarks
PCB5 PFLP1431MZ SENSOR BOARD ASS'Y (RTL)
(CONNECTOR)
CN501 PQJP3G43Z CONNECTOR, 3 PIN S
(SWITCHES)
SW501 K0MA11000030 REED SW, FILM DETECTION
SW502 PFSH1A011Z PUSH SWITCH, COVER OPEN
12.7. FIXTURES AND TOOLS
Ref. No. Part No. Part Name & Description Remarks
EC1 PFZZ16K5Z EXTENSION CORD, 16 PIN
EC2 PQZZ2K12Z EXTENSION CORD, 2 PIN
EC3 PQZZ7K5Z EXTENSION CORD, 7 PIN
EC4 PFZZ11K12Z EXTENSION CORD, 11 PIN
EC5 PFZZ5K13Z EXTENSION CORD, 5 PIN
EC6 PQZZ5K6Z EXTENSION CORD, 5 PIN
EC7 PQZZ3K5Z EXTENSION CORD, 3 PIN
EC8 PQZZ8K18Z EXTENSION CORD, 8 PIN
EC9 PFZZ10K1Z EXTENSION CORD, 10 PIN
EC10 PQZZ2K13Z EXTENSION CORD, 2 PIN
KM79811245C0 BASIC FACSIMILE TECHNIQUE
Note:
Tools and Extension Cords are useful for servicing.
(They make servicing easy.)
13. PRINTED CIRCUIT BOARD
13.1. DIGITAL BOARD (PCB1)
13.1.1. DIGITAL BOARD: COMPONENT VIEW
226
