Panasonic KX-FP342CX

Test Mode Type of
Mode
Code Function
Operation after
code input
SENSOR
CHECK & VOX
CHECK
Service
Mode
“8” “1” “5” If you enter this mode and operate sensor levers
with
hands, the LCD display of the related sensor (or
switch)
turns ON / OFF. Also, when copying a document,
the
sensor willturn ON / OFF. ( Do, Sn, Co, Pt, Vx)
For each sensor’s operation, refer to SENSORS
AND
SWITCHES().
[Do Sn Co Pt Vx] : LCD DISPLAY
Do: Document set sensor
:Paper inserted. Turns on when a document is
inserted.
Sn: Read position sensor.
:At the read position, turns on when the front
cover
opened and the sensor lever is pressed directory.
Co: Cover open sensor / Film end sensor
:Cover open of don’t set the film. Turns on and
off
front cover is opened and closed.
Pt: Paper top sensor
:Sensor on Turns on when the front cover is
opened
sensor lever is pressed directly.
Vx: Vox signal
:Detection signal for the tone on the line. Turns
on
there is a tone signal on the line.
START
Note:
The numbers in the boxes (XXX) indicate the keys to be input for the
various test modes.
6.3.1. DTMF SINGLE TONE TRANSMIT SELECTION
When set to ON (=1), the 12 keys and transmission frequencies are as shown.
70
