Ref. No. Part No. Part Name & Description Remarks
C112 ECUV1H123KBV 0.012 S
C113 ECUV1C104KBV 0.1 S
C114 ECUV1C104KBV 0.1 S
C115 ECUV1H123KBV 0.012 S
C116 ECUV1H820JCV 82P S
C118 ECUV1H104ZFV 0.1 S
C122 ECUV1H153KBV 0.015 S
C124 ECUV1H471JCV 470P S
C125 ECEA1HKS100 10 S
C131 ECUV1H103KBV 0.01 S
C132 ECEA1CKS100 10 S
C133 ECEA1CKS470 47 S
C134 ECUV1H472KBV 0.0047 S
C136 ECEA1CKS470 47 S
C137 ECUV1H103KBV 0.01 S
C138 ECUV1H103KBV 0.01 S
C139 ECUV1C104KBV 0.1 S
C140 ECUV1C104KBV 0.1 S
C142 ECUV1H221JCV 220P S
C159 ECUV1H103KBV 0.01 S
C171 ECEA1HKA4R7 4.7
C172 ECUV1C393KBV 0.039 S
C173 ECUV1H102KBV 0.001 S
C175 ECUV1H681KBV 680P S
C176 ECUV1H681KBV 680P S
12.4. OPERATION BOARD PARTS
Ref. No. Part No. Part Name & Description Remarks
PCB3 PFWP3FHD331M OPERATION BOARD ASS'Y (RTL)
(IC)
IC301 MN7D032Z9J IC
(DIODE)
LED302 PQVDSLR325MC LED S
(LCD)
CN302 L5DAAFB00001 LIQUID CRYSTAL DISPLAY
(CONNECTOR)
CN301 PQJP8G43Y CONNECTOR, 8 PIN S
(SWITCHES)
SW301 PQSH1A105Z PUSH SWITCH S
SW302 PQSH1A105Z PUSH SWITCH S
SW303 PQSH1A105Z PUSH SWITCH S
SW304 PQSH1A105Z PUSH SWITCH S
SW305 PQSH1A105Z PUSH SWITCH S
SW306 PQSH1A105Z PUSH SWITCH S
SW307 PQSH1A105Z PUSH SWITCH S
SW308 PQSH1A105Z PUSH SWITCH S
222
