CROSS REFERENCE:
A-1 : HOW TO REMOVE THE PAPER TRAY AND RECORDING PAPER SUPPORT ()
B-1 : HOW TO REMOVE THE BOTTOM FRAME ()
B-2 : HOW TO REMOVE THE DIGITAL, ANALOG, POWER SUPPLY, SENSOR BOARDS AND AC
INLET ()
B-3 : HOW TO REMOVE THE MOTOR BLOCK AND SEPARATION ROLLER ()
B-4 : HOW TO REMOVE THE GEARS OF MOTOR BLOCK ()
5.2. DISASSEMBLY PROCEDURE
5.2.1. HOW TO REMOVE THE PAPER TRAY AND RECORDING PAPER SUPPORT
47
