Panasonic KX-FP342CX

Ref. No. Part No. Part Name & Description Remarks
PCB2 PFWP2FP342CX ANALOG BOARD ASS'Y (RTL)
(ICs)
IC101 PQVINJM2904F IC S
IC102 PQVIMC34119M IC S
(TRANSISTORS)
Q101 2SD1819A TRANSISTOR(SI) S
Q102 PQVTDTC143E TRANSISTOR(SI) S
Q103 2SD1819A TRANSISTOR(SI) S
(DIODES)
D101 MA4056 DIODE(SI)
D102 MA4056 DIODE(SI)
D103 1SS119 DIODE(SI) S
D105 1SS119 DIODE(SI) S
D106 1SS119 DIODE(SI) S
D110 MA4030 DIODE(SI) S
D110 MA4030 DIODE(SI) S
(CONNECTORS AND JACKS)
CN101 PQJS16A10Z CONNECTOR, 16 PIN S
CN102 PFJJ1T01Z JACK S
CN103 PFJJ1T01Z JACK S
CN104 PQJJ1TB18Z JACK S
CN105 PQJP02G100Z CONNECTOR, 2 PIN
(SWITCH)
SW101 PFSH1A011Z SWITCH, HOOK
(COILS)
L102 PQLQR2KA213 COIL S
L103 PQLQR2KA213 COIL S
L104 PQLQR2KA213 COIL S
L105 PQLQR2KA213 COIL S
L107 PQLQR2KA113 COIL S
L108 PQLQR2KA113 COIL S
L109 PQLQR2KA113 COIL S
L110 PQLQR2KA113 COIL S
(PHOTO COUPLERS)
PC101 0N3181 PHOTO ELECTRIC TRANSDUCER
PC105 CNC7S102 PHOTO ELECTRIC TRANSDUCER
(POSISTOR)
POS101 PQRPAR390N THERMISTOR
S
(RELAY)
RLY101 PFSL003Z RELAY
S
(SURGE ABSORBERS)
SA101 PQVDDSS301L VARISTOR S
220
