Panasonic KX-TDA100D

<Modification Flowchart>
A trunk call with the caller's
information is received.
No:
e.g., 3344556677
Yes:
e.g., 00987654321
Is the area code found in
local/international call data
in the modification table?
Modifies the number as programmed.
Checks the local/
international call data.
Modification is completed:
001987654321.
Modification is completed:
03344556677.
Modifies the number as programmed.
(Removed number of digits: 0,
Added number: 0)
Checks the long distance call data.
Matches (Data 2)
Table 1
Removed number of digits: 2
Added number: 001
Received number: 00987654321
Modified number: 00987654321 = 001987654321
1) Remove the
first 2 digits.
2) Add "001".
Checks the Table Selection.
Caller ID Table Assignment
The System Speed Dialling Table is also used as the Caller ID Table.
In each location of the table, the following items can be assigned:
a. Telephone number (Trunk Access number + caller’s telephone number)
b. System Speed Dialling name (caller’s name)
(shown on the display or SMDR)
c. CLI destination
(used for CLI feature)
When a caller’s modified telephone number matches a telephone number (the Trunk Access number is
disregarded.) in the table, the call is sent to the assigned CLI destination.
[Example]
Location (System Speed
Dialling No.)
Telephone No.
*1
System Speed Dialling
Name
*2
CLI Destination
*3
000 90123456789 ABC Company 200
001 : : :
: : : :
*1
® 8.1 [6-1] System Speed Dial— CO Line Access Number + Telephone Number
212 Feature Guide
1.18.1 Caller ID
