Panasonic KX-TDA30

1.18 Caller ID Features
Feature Guide 227
<Modification Flowchart>
3.2 Caller ID Table Assignment
The System Speed Dialling Table is also used as the Caller ID Table.
In each location of the table, the following items can be assigned:
a) Telephone number (Trunk Access number + caller's telephone number)
b) System Speed Dialling name (caller's name)
(shown on the display or SMDR)
c) CLI destination
(used for CLI feature)
When a caller's modified telephone number matches a telephone number (the Trunk Access
number is disregarded.) in the table, the call is sent to the assigned CLI destination.
[Example]
Location (System Speed
Dialling No.)
Telephone No.
*1
System Speed Dialling
Name
*2
CLI Destination
*3
000 90123456789 ABC Company 200
001 : : :
::::
A trunk call with the caller's
information is received.
No:
e.g., 3344556677
Yes:
e.g., 00987654321
Is the area code found in
local/international call data
in the modification table?
Modifies the number as programmed.
Checks the local/
international call data.
Modification is completed:
001987654321.
Modification is completed:
03344556677.
Modifies the number as programmed.
(Removed number of digits: 0,
Added number: 0)
Checks the long distance call data.
Matches (Data 2)
Table 1
Removed number of digits: 2
Added number: 001
Received number: 00987654321
Modified number: 00987654321 = 001987654321
1) Remove the
first 2 digits.
2) Add "001".
Checks the Table Selection.
