254
SQW0038
Wi-Fi
Using WEB services
Quickly sending pictures in the camera to WEB services
Once you send a picture, you can send pictures to the WEB service as quickly and
easily as using a smartphone, only when the environment for connecting to a wireless
access point is available.
Display the picture
Use to select [Yes] after pressing
(When a group picture is being displayed, select
[Upload(Wi-Fi)] → [Yes])
The camera is connected to the previously used wireless access
point and the pictures are sent to the WEB service.
*
1,
*
2
Upload this image by Wi-Fi?Upload this image by Wi-Fi?
YesYes
NoNo
*
1
When no connection history is available for the wireless access point, proceed to the connection
method selection screen. Select the connection method and connect the camera to a wireless
access point. (→264)
*
2
If you do not have a “LUMIX CLUB” login ID, proceed to the new login ID sign up screen. Get a
login ID and set a password. (→259)
Performing the operation for the first time
After you select [Yes] in step above, the WEB service selection screen appears.
Use to select WEB services and press [MENU/SET]
Check the setting on the confirmation screen for the transmission setting and press
[MENU/SET]
The picture is sent to the WEB service.
To change the transmission setting for the picture, press the [DISP.] button. (→271)
After the second time, the pictures are sent using the same WEB service and the same
picture transmission settings as before.
When pictures are displayed as a group, they are all sent. When a single picture in a group is
displayed, only the picture being displayed is sent.
To change the transmission settings of a picture or to close the Wi-Fi connection, press the [Wi-Fi]
button. You can also close the connection by pressing the Playback button or [MENU/SET] and
selecting [Yes]. When you switch to Recording Mode, the Wi-Fi connection is closed.

Table of Contents

Other manuals for Panasonic Lumix DMC-LX100

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Panasonic Lumix DMC-LX100 and is the answer not in the manual?

Panasonic Lumix DMC-LX100 Specifications

General IconGeneral
Megapixel12.8 MP
Camera typeCompact camera
Sensor typeMOS
Image stabilizerYes
Total megapixels16.84 MP
Image sensor size4/3 \
Image formats supportedJPG, RAW
Supported aspect ratios1:1, 3:2, 4:3, 16:9
Maximum image resolution4112 x 3088 pixels
Still image resolution(s)[4:3] 4112x3088 (12.5M) (L) / 2976x2232 (6.5M) (M) / 2048x1536 (3M) (S)/[3:2] 4272x2856 (12M) (L) / 3120x2086 (6.5M) (M) / 2112x1408 (3M) (S)/[16:9] 4480x2520 (11M) (L) / 3840x2160 (8M) (M) / 1920x1080 (2M) (S)/[1:1] 3088x3088 (10M) (L) / 2240x2240 (5M) (M) / 1536x1536 (2.5M) (S)
Digital zoom4 x
Optical zoom3.1 x
Focal length range10.9 - 34 mm
Maximum aperture number16
Minimum aperture number1.7
Lens structure (elements/groups)11/8
Maximum focal length (35mm film equiv)75 mm
Minimum focal length (35mm film equiv)24 mm
Focus adjustmentAuto/Manual
Normal focusing range0.5 - ∞ m
Auto focusing (AF) modesContinuous Auto Focus, Single Auto Focus
Light meteringCentre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity100, 200, 400, 800, 1600, 3200, 6400, 12800, 25600
Light exposure modesAperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)51200
ISO sensitivity (min)100
Light exposure controlProgram AE
Light exposure correction± 3EV (1/3EV step)
Fastest camera shutter speed1/16000 s
Slowest camera shutter speed60 s
Flash modesAuto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash range (tele)0.3 - 8.5 m
Flash range (wide)0.6 - 14.1 m
Shoe mounting point typeHot shoe
Video resolutions1280 x 720, 1920 x 1080, 3840 x 2160 pixels
Maximum video resolution3840 x 2160 pixels
Analog signal format systemNTSC, PAL
Resolution at capture speed1280x960@25fps, 1920x1080@24fps, 1920x1080@25fps, 1920x1080@50fps
Audio formats supportedAAC
Memory slots1
Internal memory- MB
Compatible memory cardsSD, SDHC, SDXC
Field of view100 %
Display diagonal3 \
Vari-angle LCD displayNo
Display resolution (numeric)921000 pixels
Magnification1.39 x
Viewfinder screen size0.38 \
USB version-
HDMI connector typeMicro
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Image editingCrop, Resizing, Rotating
Photo effectsArt, Black&White, Neutral, Sepia, Vivid
White balanceAuto, Cloudy, Daylight, Flash, Incandescent, Shade
Camera playbackSlide show, Thumbnails
Image processorVenus
Self-timer delay2, 10 s
Camera file systemDCF, DPOF, Exif 2.3, RAW
Image quality adjustmentColour depth, Contrast, Saturation, Sharpness
On Screen Display (OSD) languagesDEU, ENG, ESP, FRE, ITA, JPN
Power source typeBattery
Battery voltage7.2 V
Battery capacity1025 mAh
Battery life (CIPA standard)350 shots
Product colorSilver
Cables includedAC, USB
Bundled softwarePHOTOfunSTUDIO 9.6PE/SILKYPIX Developer Studio\\r LoiLoScope (trial)\\r Adobe Reader
Weight and Dimensions IconWeight and Dimensions
Depth55 mm
Width114.8 mm
Height66.2 mm
Weight351 g
Weight (including battery)393 g
