Panasonic Lumix DMC-LX100 Operating Instructions

314
SQW0038
Others
Q&A Troubleshooting
■
Monitor/viewfinder
The monitor/viewfinder is turned off although the camera is turned on.
• When a hand or object is close to the eye sensor, the monitor display mode could be switched to
viewfinder display mode without your knowledge. (→54)
Pictures do not show on the monitor.
• Viewfinder display mode is activated.
→ Press the [LVF] button to switch to the monitor display mode. (→54)
• Monitor is turned off.
→ Press the [DISP.] button to switch the display information. (→62)
• When you connect the camera to a TV using an HDMI micro cable, the picture is not displayed on
a monitor/viewfinder in the following cases.
– During playback
Brightness is unstable.
• Aperture value is set while shutter button is pressed halfway. (Does not affect recorded picture.)
This symptom may also occur when the brightness changes because the zoom is operated or the
camera is moved. This is the automatic aperture operation of the camera and is not a malfunction.
The screen flickers indoors.
• The screen may flicker for a few seconds after turning on. This is an operation to correct flicker
caused by lighting such as fluorescent lights, LED lights, etc. and is not a malfunction.
The screen is too bright/too dark.
• Check [Monitor Luminance] setting. (→45)
• Use [Monitor Display]/[Viewfinder] to adjust the brightness of the screen. (→44)
Black/blue/red/green dots or interference appears. Monitor looks distorted when touched.
• This is not a fault, and will not be recorded on the actual pictures.
Noise appears on the monitor/viewfinder.
• In dark places, noise may appear to maintain the brightness of the monitor/viewfinder.
Cannot switch between the monitor and viewfinder when pressing [LVF] button.
• When it is connected to a computer or printer, the camera can display pictures on the monitor only.

Panasonic Lumix DMC-LX100 Specifications

General

Megapixel	12.8 MP
Camera type	Compact camera
Sensor type	MOS
Image stabilizer	Yes
Total megapixels	16.84 MP
Image sensor size	4/3 \
Image formats supported	JPG, RAW
Supported aspect ratios	1:1, 3:2, 4:3, 16:9
Maximum image resolution	4112 x 3088 pixels
Still image resolution(s)	[4:3] 4112x3088 (12.5M) (L) / 2976x2232 (6.5M) (M) / 2048x1536 (3M) (S)/[3:2] 4272x2856 (12M) (L) / 3120x2086 (6.5M) (M) / 2112x1408 (3M) (S)/[16:9] 4480x2520 (11M) (L) / 3840x2160 (8M) (M) / 1920x1080 (2M) (S)/[1:1] 3088x3088 (10M) (L) / 2240x2240 (5M) (M) / 1536x1536 (2.5M) (S)
Digital zoom	4 x
Optical zoom	3.1 x
Focal length range	10.9 - 34 mm
Maximum aperture number	16
Minimum aperture number	1.7
Lens structure (elements/groups)	11/8
Maximum focal length (35mm film equiv)	75 mm
Minimum focal length (35mm film equiv)	24 mm
Focus adjustment	Auto/Manual
Normal focusing range	0.5 - ∞ m
Auto focusing (AF) modes	Continuous Auto Focus, Single Auto Focus
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 200, 400, 800, 1600, 3200, 6400, 12800, 25600
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	51200
ISO sensitivity (min)	100
Light exposure control	Program AE
Light exposure correction	± 3EV (1/3EV step)
Fastest camera shutter speed	1/16000 s
Slowest camera shutter speed	60 s
Flash modes	Auto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash range (tele)	0.3 - 8.5 m
Flash range (wide)	0.6 - 14.1 m
Shoe mounting point type	Hot shoe
Video resolutions	1280 x 720, 1920 x 1080, 3840 x 2160 pixels
Maximum video resolution	3840 x 2160 pixels
Analog signal format system	NTSC, PAL
Resolution at capture speed	1280x960@25fps, 1920x1080@24fps, 1920x1080@25fps, 1920x1080@50fps
Audio formats supported	AAC
Memory slots	1
Internal memory	- MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Vari-angle LCD display	No
Display resolution (numeric)	921000 pixels
Magnification	1.39 x
Viewfinder screen size	0.38 \
USB version	-
HDMI connector type	Micro
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Image editing	Crop, Resizing, Rotating
Photo effects	Art, Black&White, Neutral, Sepia, Vivid
White balance	Auto, Cloudy, Daylight, Flash, Incandescent, Shade
Camera playback	Slide show, Thumbnails
Image processor	Venus
Self-timer delay	2, 10 s
Camera file system	DCF, DPOF, Exif 2.3, RAW
Image quality adjustment	Colour depth, Contrast, Saturation, Sharpness
On Screen Display (OSD) languages	DEU, ENG, ESP, FRE, ITA, JPN
Power source type	Battery
Battery voltage	7.2 V
Battery capacity	1025 mAh
Battery life (CIPA standard)	350 shots
Product color	Silver
Cables included	AC, USB
Bundled software	PHOTOfunSTUDIO 9.6PE/SILKYPIX Developer Studio\\r LoiLoScope (trial)\\r Adobe Reader

Weight and Dimensions

Depth	55 mm
Width	114.8 mm
Height	66.2 mm
Weight	351 g
Weight (including battery)	393 g
