Chapter 4 Settings — [DISPLAY OPTION] menu
100 - ENGLISH
[AUTO] Automatically sets the signal level.
[64-940]
Select when the HDMI terminal output of an external device (such as a blu-ray disc player) is
connected to the <DIGITAL LINK/LAN> terminal via a twisted-pair-cable transmitter.
[0-1023]
Select this when the DVI-D terminal output or HDMI terminal output of an external device (such as a
computer) is connected to the <DIGITAL LINK/LAN> terminal via a twisted-pair-cable transmitter.
Note
f The optimal setting varies depending on the output setting of the connected external device. Refer to the operating instructions of the
external device regarding the output of the external device.
[SDI IN]
(Only for PT-DZ870E)
Set to match the signal to input to the <SDI IN> terminal.
Setting [SIGNAL LEVEL]
Select the amplitude of the signal to input.
1) Press as to select [SDI IN].
2) Press the <ENTER> button.
f The [SDI IN] screen is displayed.
3) Press as to select [SIGNAL LEVEL].
4) Press qw to switch the item.
[64-940] Normally use this setting.
[4-1019] Select when gray is displayed as black.
Setting [BIT DEPTH]
1) Press as to select [SDI IN].
2) Press the <ENTER> button.
f The [SDI IN] screen is displayed.
3) Press as to select [BIT DEPTH].
4) Press qw to switch the item.
[AUTO] Automatically select 12 bits or 10 bits.
[12-bit] Fix to 12 bits.
[10-bit] Fix to 10 bits.
Setting [3G-SDI MAPPING]
1) Press as to select [SDI IN].
2) Press the <ENTER> button.
f The [SDI IN] screen is displayed.
3) Press as to select [3G-SDI MAPPING].
4) Press qw to switch the item.
[AUTO] Automatically select level A or level B.
[LEVEL A] Fix to level A.
[LEVEL B] Fix to level B.
Note
f Does not operate during SD-SDI or HD-SDI input.
