Panasonic PT-DZ870E

Chapter 4 Settings — [PROJECTOR SETUP] menu
118 - ENGLISH
3) Press asqw to select an input.
f The items will switch each time you press the button.
[LAST USED] Keeps the input selected last.
[VIDEO] Sets the input to VIDEO.
[RGB1] Sets the input to RGB1.
[RGB2] Sets the input to RGB2.
[DVI-D] Sets the input to DVI-D.
[HDMI] Sets the input to HDMI.
[DIGITAL LINK] Sets the input to DIGITAL LINK.
[SDI]
*1
Sets the input to SDI.
[INPUT1] - [INPUT10]
*2
Sets the input to DIGITAL LINK, and switch the input of Panasonic twisted-pair-cable transmitter to
the specied input.
*1 Only for PT-DZ870E
*2 When the Panasonic twisted-pair-cable transmitter (such as the optional Digital Interface Box (Model No.: ET-YFB100G)) is connected to the
projector, its input name is reected from [INPUT1] to [INPUT10] automatically. If an item where the input name is not reected is selected, it
is disabled.
4) Press the <ENTER> button.
[RS-232C]
Set the communication conditions of the <SERIAL IN>/<SERIAL OUT> terminal.
Setting the communication condition of the <SERIAL IN> terminal
1) Press as to select [RS-232C].
2) Press the <ENTER> button.
f The [RS-232C] screen is displayed.
3) Press as to select [INPUT SELECT].
4) Press qw to switch the item.
[PROJECTOR] Use the <SERIAL IN> terminal of the projector to execute RS-232C communication.
[DIGITAL INTERFACE BOX]
Executes RS-232C communication via the optional Digital Interface Box (Model No.: ET-YFB100G)
and the <DIGITAL LINK/LAN> terminal.
5) Press as to select [(IN) BAUDRATE].
6) Press qw to switch the item.
f The items will switch each time you press the button.
[9600]
Select the proper speed.[19200]
[38400]
7) Press as to select [(IN) PARITY].
8) Press qw to switch the item.
f The items will switch each time you press the button.
[NONE]
Select the parity condition.[EVEN]
[ODD]
Setting the communication condition of the <SERIAL OUT> terminal
1) Press as to select [RS-232C].
2) Press the <ENTER> button.
f The [RS-232C] screen is displayed.
3) Press as to select [(OUT) BAUDRATE].
