Panasonic PT-DZ870E

Chapter 4 Settings — [PROJECTOR SETUP] menu
120 - ENGLISH
[SIGNAL FREQUENCY] Displays the frequency of the input signal.
[PROJECTOR RUNTIME] Displays the operation times of the projector.
[LAMP1]
*3
Displays the runtime and status of Lamp 1.
[LAMP2]
*3
Displays the runtime and status of Lamp 2.
[INTAKE AIR TEMP.]
*2
Displays the status of the air intake temperature of the projector.
[OPTICS MODULE TEMP.]
*2
Displays the status of the internal temperature of the projector.
[AROUND LAMP TEMP.]
*2
Displays the status of the temperature around the lamps of the projector.
[PROJECTOR TYPE] Displays the type of the projector.
[SERIAL NUMBER] Displays the serial number of the projector.
[LAMP UNIT MODEL NO.] Displays the model no. of the lamp unit.
[LAMP1 SERIAL NUMBER] Displays the serial number of the lamp 1.
[LAMP2 SERIAL NUMBER] Displays the serial number of the lamp 2.
[MAIN VERSION] Displays the main version of the rmware of the projector.
[SUB VERSION] Displays the sub version of the rmware of the projector.
[UPGRADE(ET-UK20)]
*1
Displays the activation status based on the Upgrade Kit.
[ON COUNT]
[POWER ON TIMES] Displays the number of times the power is turned on.
[LAMP1 ON]
Displays the number of times the lamp is turned on.
[LAMP2 ON]
[SHUTTER] Displays the number of times the shutter is closed.
[LAMP1] Displays runtime in detail.
[LAMP2] Displays runtime in detail.
[NUMBER OF REGISTERED
SIGNAL]
Displays the number of registered signals.
[REMOTE2 STATUS] Displays the control status of the REMOTE2.
[AC VOLTAGE] Displays the status of the AC voltage.
[COOLING CONDITION] Displays the set cooling conditions. When [AUTO] is set, automatically recognized result is displayed.
[SIGNAL INFORMATION]
[MEMORY NO.] Displays the memory number of the input signal.
[INPUT] Displays the input terminal currently selected.
[SIGNAL NAME] Displays the input signal name.
[SIGNAL FREQUENCY] Displays the frequency of the input signal.
[SYNC.STATE] Displays the synch polarity of the input signal.
[V.SYNC WIDTH] Displays the vertical sync signal pulse width of the input signal.
[SCAN TYPE] Displays the scan type of the input signal.
[TOTAL DOTS] Displays the total dot count of the input signal.
[DISPLAY DOTS] Displays the number of input signal display dots.
[TOTAL LINES] Displays the total line count of the input signal.
[DISPLAY LINES] Displays the number of input signal display lines.
[SAMPLING] Displays the sampling information of the input signal.
[SIGNAL LEVEL] Displays the signal level of the input signal.
[BIT DEPTH]
*1
Displays the gradation of the input signal.
*1 Only for PT-DZ870E
*2 The temperature status is displayed with text color (green/yellow/red) and bar scale. Use the projector within the indication in green.
*3 The lamp runtime to be displayed is real time. The following conversion is required to calculate the rough estimate for lamp replacement.
Formula for lamp replacement time (rough estimate)
(A x 4 + B x 3) ÷ 4
f A: Runtime when [LAMP POWER] is set to [NORMAL]
f B: Runtime when [LAMP POWER] is set to [ECO]
The formula when the optional Replacement lamp unit (for portrait mode) is used is:
(A x 13 + B x 10) ÷ 13
Note
f The content of status can be sent via E-mail by pressing the <ENTER> button while displaying the [STATUS] screen.
f Some items in [SIGNAL INFORMATION] may be displayed and others not displayed, depending on the signal being input.
[NO SIGNAL SHUT-OFF]
A function that automatically switches the power source of the projector to standby if there is no input signal for a certain period of time. The
time before switching to standby can be set.
1) Press as to select [NO SIGNAL SHUT-OFF].
