Panasonic PT-DZ870E

Chapter 4 Settings — [PROJECTOR SETUP] menu
ENGLISH - 121
2) Press qw to switch the item.
f The items will switch each time you press the button.
[DISABLE] Disables the No signal shut-off function.
[10MIN.] - [90MIN.] Allows you to set in ten minutes intervals.
[REMOTE2 MODE]
You can set the <REMOTE 2 IN> terminal.
1) Press as to select [REMOTE2 MODE].
2) Press qw to switch the item.
f The items will switch each time you press the button.
[DEFAULT]
The pin assignment of the <REMOTE 2 IN> terminal is used by the factory default setting of the
projector.
[USER] Used to change the setting of the <REMOTE 2 IN> terminal.
[L6500 SERIES] The setting of <REMOTE 2 IN> terminal is used for the L6500 series compatibility.
f When [USER] is selected, proceed to Step 3).
3) Press the <ENTER> button.
4) Press as to select one from [PIN2] to [PIN8], and press qw to switch the setting.
[FUNCTION BUTTON]
Set the functions of the <FUNCTION> button on the remote control.
1) Press as to select [FUNCTION BUTTON].
2) Press the <ENTER> button.
f The [FUNCTION BUTTON] screen is displayed.
3) Press as to select a function.
[DISABLE] Disables the <FUNCTION> button.
[P IN P]
Switches the [P IN P] setting to [OFF], [USER1], [USER2], or [USER3]. (x page 124)
[SUB MEMORY]
Displays the sub memory list. (x page 129)
[SYSTEM SELECTOR]
Switches the [SYSTEM SELECTOR] setting. (x page 76)
[SYSTEM DAYLIGHT VIEW]
Switches the [SYSTEM DAYLIGHT VIEW] setting. (x page 74)
[FREEZE]
Temporarily pauses the image. (x page 105)
[WAVEFORM MONITOR]
Displays the waveform of the input signal. (x page 105)
[LEFT/RIGHT SWAP]
Switches the ip horizontal settings. (x page 92)
[ASPECT]
Switches the aspect setting. (x page 78)
4) Press the <ENTER> button.
[DATE AND TIME]
Set the time zone, date, and time of the built-in clock of the projector.
Setting the time zone
1) Press as to select [DATE AND TIME].
2) Press the <ENTER> button.
f The [DATE AND TIME] screen is displayed.
3) Press as to select [TIME ZONE].
4) Press qw to switch [TIME ZONE].
