Chapter 4 Settings — [PROJECTOR SETUP] menu
ENGLISH - 119
4) Press qw to switch the item.
[9600]
Select the proper speed.[19200]
[38400]
5) Press as to select [(OUT) PARITY].
6) Press qw to switch the item.
f The items will switch each time you press the button.
[NONE]
Select the parity condition.[EVEN]
[ODD]
Setting the response
1) Press as to select [RS-232C].
2) Press the <ENTER> button.
f The [RS-232C] screen is displayed.
3) Press as to select [RESPONSE(ID ALL)].
4) Press qw to switch the item.
[ON] Returns the response when the ID setting is ALL.
[OFF] Does not return the response when the ID setting is ALL.
5) Press as to select [GROUP].
6) Press qw to switch the item.
[A] - [Z]
Controls multiple projectors simultaneously by sending the ID of RS-232C. You can set groups from
[A] to [Z]. The projector responds when the ID of RS-232C matches the setting.
7) Press as to select [RESPONSE(ID GROUP)].
8) Press qw to switch the item.
[ON] Returns the response when the ID setting is GROUP.
[OFF] Does not return the response when the ID setting is GROUP.
Note
f When [INPUT SELECT] is set to [DIGITAL INTERFACE BOX], communication using that serial terminal is available only when the
corresponding device (such as the optional Digital Interface Box (Model No.: ET-YFB100G)) is connected to the <DIGITAL LINK/LAN>
terminal.
f When transferring logos via the optional Digital Interface Box (Model No.: ET-YFB100G), “NO SIGNAL SLEEP” of ET-YFB100G must be set
to “OFF” to avoid cutting off communication.
f When [INPUT SELECT] is set to [DIGITAL INTERFACE BOX], communication speed is xed to 9 600 bps.
[STATUS]
Display the status of the projector.
1) Press as to select [STATUS].
2) Press the <ENTER> button.
f The [STATUS] screen is displayed.
3) Press qw to switch the pages.
f The page will change each time you press the button.
[INPUT] Displays the input terminal currently selected.
[SIGNAL NAME] Displays the input signal name.
To Next Page
