Panasonic PT-DZ870E

Chapter 6 Appendix — Technical information
ENGLISH - 169
Channel Control details Performance Parameter Remark
8 Fade-in time setting
0.0s 0-15
Operate together with channel 1.
0.5s 16-31
1.0s 32-47
1.5s 48-63
2.0s 64-79
2.5s 80-95
3.0s 96-111
3.5s 112-127
4.0s 128-143
5.0s 144-159
7.0s 160-175
10.0s 176-191
No operation 192-255
9 Fade-out time setting
0.0s 0-15
Operate together with channel 1.
0.5s 16-31
1.0s 32-47
1.5s 48-63
2.0s 64-79
2.5s 80-95
3.0s 96-111
3.5s 112-127
4.0s 128-143
5.0s 144-159
7.0s 160-175
10.0s 176-191
No operation 192-255
10 Custom masking
OFF 0-31
To use this function, the optional
Upgrade Kit (Model No.: ET-UK20) is
required.
PC-1 32-63
PC-2 64-95
PC-3 96-127
No operation 128-255
11 Geometry
OFF 0-15
(Only for PT-DZ870E)
To use PC-1, PC-2, or PC-3, the
optional Upgrade Kit (Model No.:
ET-UK20) is required.
KEYSTONE 16-31
CURVED 32-47
PC-1 48-63
PC-2 64-79
PC-3 80-95
CORNER CORRECTION 96-111
No operation 112-255
Note
f If the projector is operated with the remote control or on the control panel, or by the control command while controlling the projector by
using the Art-Net function, the setting of the DMX controller and the computer application may be different from the projector status. In that
case, set the “Lock” setting of the channel 7 to “Operation not available” and then reset to “Operation available”. The controls of all channels
become reected to the projector.
