Panasonic PT-DZ870E

Chapter 6 Appendix — Technical information
182 - ENGLISH
3D compatible
signal
Resolution
(Dots)
Scanning freq.
Dot clock
freq.
(MHz)
RGB1/RGB2 SDI
*1
H-D R1-2
Horizontal
(kHz)
Vertical
(Hz)
SBS
*2
TB LBL FS SBS
*2
TB LBL 3G
750 (720)/60p 1 280 x 720 45.0 60.0 74.3
l l l
―
l l l l l l
750 (720)/50p 1 280 x 720 37.5 50.0 74.3
l l l
―
l l l l l l
1080/60i 1 920 x 1 080i 33.8 60.0 74.3
l l
― ―
l l
―
l l l
1080/50i 1 920 x 1 080i 28.1 50.0 74.3
l l
― ―
l l
―
l l l
1080/24p 1 920 x 1 080 27.0 24.0 74.3
l l
― ―
l l
―
l l l
1080/24sF 1 920 x 1 080i 27.0 48.0 74.3
l l
― ―
l l
―
l l l
1080/25p 1 920 x 1 080 28.1 25.0 74.3
l l
― ―
l l
―
l l l
1080/30p 1 920 x 1 080 33.8 30.0 74.3
l l
― ―
l l
―
l l l
1080/60p 1 920 x 1 080 67.5 60.0 148.5
l l
― ―
l l
― ―
l l
1080/50p 1 920 x 1 080 56.3 50.0 148.5
l l
― ―
l l
― ―
l l
VGA480 640 x 480 31.5 59.9 25.2
l
― ― ― ― ― ― ― ― ―
SVGA 800 x 600 37.9 60.3 40.0
l
― ― ― ― ― ― ― ― ―
XGA
1 024 x 768 39.6 50.0 51.9
l
― ― ― ― ― ― ―
l l
1 024 x 768 48.4 60.0 65.0
l
― ― ― ― ― ― ―
l l
1 024 x 768 81.4 100.0 113.3 ― ― ―
l
― ― ― ― ― ―
1 024 x 768 98.8 120.0 139.1 ― ― ―
l
― ― ― ― ― ―
MXGA 1 152 x 864 53.7 60.0 81.6
l
― ― ― ― ― ― ― ― ―
1280 x 720
1 280 x 720 37.1 49.8 60.5
l
― ― ― ― ― ― ― ― ―
1 280 x 720 44.8 59.9 74.5
l
― ― ― ― ― ― ― ― ―
1 280 x 720 76.3 100.0 131.8 ― ― ―
l
― ― ― ― ― ―
1 280 x 720 92.6 120.0 161.6 ― ― ―
l
― ― ― ― ― ―
1280 x 768
1 280 x 768 39.6 49.9 65.3
l
― ― ― ― ― ― ― ― ―
1 280 x 768 47.8 59.9 79.5
l
― ― ― ― ― ― ― ― ―
1 280 x 768
*3
47.4 60.0 68.3
l
― ― ― ― ― ― ― ― ―
1280 x 800
1 280 x 800 41.3 50.0 68.0
l
― ― ― ― ― ― ―
l l
1 280 x 800 49.7 59.8 83.5
l
― ― ― ― ― ― ―
l l
1
280 x 800
*3
49.3 59.9 71.0
l
― ― ― ― ― ― ―
l l
MSXGA 1 280 x 960 60.0 60.0 108.0
l
― ― ― ― ― ― ― ― ―
SXGA
1 280 x 1 024 52.4 50.0 88.0
l
― ― ― ― ― ― ― ― ―
1 280 x 1 024 64.0 60.0 108.0
l
― ― ― ― ― ― ― ― ―
1366 x 768
1 366 x 768 47.7 59.8 85.5
l
― ― ― ― ― ― ― ― ―
1 366 x 768 39.6 49.9 69.0
l
― ― ― ― ― ― ― ― ―
SXGA+
1 400 x 1 050 54.1 50.0 99.9
l
― ― ― ― ― ― ― ― ―
1 400 x 1 050 64.0 60.0 108.0
l
― ― ― ― ― ― ― ― ―
1 400 x 1 050 65.2 60.0 122.6
l
― ― ― ― ― ― ― ― ―
1 400 x 1 050 65.3 60.0 121.8
l
― ― ― ― ― ― ― ― ―
WXGA+
1 440 x 900 55.9 59.9 106.5
l
― ― ― ― ― ― ― ― ―
1 440 x 900 46.3 49.9 86.8
l
― ― ― ― ― ― ― ― ―
UXGA60 1 600 x 1 200 75.0 60.0 162.0
l
― ― ― ― ― ― ― ― ―
WSXGA+
1 680 x 1 050 65.3 60.0 146.3
l
― ― ― ― ― ― ― ― ―
1 680 x 1 050 54.1 50.0 119.5
l
― ― ― ― ― ― ― ― ―
1920 x 1080
1 920 x 1 080 55.6 49.9 141.5
l
― ― ― ― ― ― ― ― ―
1 920 x 1 080
*3
66.6 59.9 138.5
l
― ― ― ― ― ― ― ― ―
WUXGA
1 920 x 1 200 61.8 49.9 158.3
l
― ― ― ― ― ― ―
l l
1 920 x 1 200
*3
74.0 60.0 154.0
l
―
l
― ― ― ― ―
l l
*1 Only for PT-DZ870E
*2 Supports half.
*3 VESA CVT RB (Reduced Blanking)-compliant
Note
f DIGITAL LINK input compatible signal is the same as HDMI input compatible signal.
