Panasonic SC-ALL2 User Manual

- 15 -
5 Select your network name (SSID) and type the password.
≥ Check the wireless router for the network name (SSID) and the password.
≥ A list of network names (SSIDs) will be appeared when you select the
“Network Name” box.
≥ To show the characters typed in the “Password” box, select “Show
Password”.
≥ If your network requires specific settings, deselect “DHCP” to disable DHCP.
– You can use specific IP address, subnet mask, default gateway, primary
DNS, etc.
6 Select “Connect” to apply the settings.
≥ When the connection is established, the network indicator (blue) lights up.
≥ Depending on the device, the connection complete screen may not be
displayed.
7 Make sure to connect your compatible device back to your
home wireless network.

≥ Enable Java and cookies in your browser settings.
If the network indicator does not light up, check the network name
(SSID) and the password, and then try the setting again.
●●●●●●●●

Panasonic SC-ALL2 Specifications

General

Speaker type	1-way
Tweeter diameter	80 mm
Number of speakers	1
Audio output channels	1.0 channels
Impedance	- Ω
Frequency range	- Hz
RMS rated power	40 W
Headphone out	Yes
Connectivity technology	Wired & Wireless
Product type	Mono portable speaker
Product color	Black
Recommended usage	Universal
Audio formats supported	AAC, FLAC, MP3, WAV
Power source type	AC
AC adapter frequency	50/60 Hz
AC adapter input voltage	100 - 240 V
Power consumption (standby)	1 W
Power consumption (typical)	22 W
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	120 mm
Width	110 mm
Height	174 mm
Weight	4200 g
