Panasonic SC-ALL2 User Manual

- 31 -
∫ Connecting a paired Bluetooth
®
device
1 Touch [ ].
≥ [ ] blinks slowly.
≥ If [ ] lights, a Bluetooth
®
device is already connected with this unit.
Disconnect it. (l below)
2 Select “SC-ALL2” from the Bluetooth
®
device’s Bluetooth
®
menu.
3 Start playback on the Bluetooth
®
device.
∫ Disconnecting a Bluetooth
®
device
Touch and hold [ ] for at least 2 seconds.
≥ [ ] blinks slowly.

≥ If prompted for the passkey, input “0000”.
≥ You can register up to 8 devices with this unit. If a 9th device is paired, the
device that has not been used for the longest time will be replaced.
≥ When [ ] is selected as the source, this unit will automatically try and
connect to the last connected Bluetooth
®
device. If the connection attempt fails,
try to establish a connection again.
≥ When the unit is selected as the speakers powered by AllPlay or DLNA, the
audio source will change to the network.
≥ Bluetooth
®
cannot be selected as the audio source when the unit is waiting for
the WPS PUSH or WPS PIN code connection.
≥ This unit can only be connected to one device at a time.
≥ When enjoying video contents with this function, the video and audio output
may not be synchronised.

Panasonic SC-ALL2 Specifications

General

Speaker type	1-way
Tweeter diameter	80 mm
Number of speakers	1
Audio output channels	1.0 channels
Impedance	- Ω
Frequency range	- Hz
RMS rated power	40 W
Headphone out	Yes
Connectivity technology	Wired & Wireless
Product type	Mono portable speaker
Product color	Black
Recommended usage	Universal
Audio formats supported	AAC, FLAC, MP3, WAV
Power source type	AC
AC adapter frequency	50/60 Hz
AC adapter input voltage	100 - 240 V
Power consumption (standby)	1 W
Power consumption (typical)	22 W
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	120 mm
Width	110 mm
Height	174 mm
Weight	4200 g
