Panasonic SC-ALL2 User Manual

- 35 -
AUX input
You can also listen to music from an external music player through this
unit.
Preparation
≥ Connect an external device. (l 11)
1 Touch [AUX].
≥ [AUX] indicator lights up.
2 Start playback on the connected device.
∫ To select the sound input level of the external device
1 While in AUX mode, touch and hold [AUX] for at least 4 seconds.
≥ “In: 0” is blinking on the display.
2 Touch [VOL –] or [VOL +] to change the setting.
In: 0: Normal level
In: 1: High level
≥ The factory default is “In: 0”.
3 Touch [DISP] to confirm the setting.

≥ To improve sound distortion when “In: 1” is selected, select “In:0”.
≥ Turn the volume of the external device down to reduce the input signal. High
level of input signal will distort the sound.
≥ For details, refer to the operating instructions of the device.
≥ When the unit is selected as the speakers powered by AllPlay or DLNA, the
audio source will change to the network.
≥ AUX cannot be selected as the audio source when the unit is waiting for the
WPS PUSH or WPS PIN code connection.

Panasonic SC-ALL2 Specifications

General

Speaker type	1-way
Tweeter diameter	80 mm
Number of speakers	1
Audio output channels	1.0 channels
Impedance	- Ω
Frequency range	- Hz
RMS rated power	40 W
Headphone out	Yes
Connectivity technology	Wired & Wireless
Product type	Mono portable speaker
Product color	Black
Recommended usage	Universal
Audio formats supported	AAC, FLAC, MP3, WAV
Power source type	AC
AC adapter frequency	50/60 Hz
AC adapter input voltage	100 - 240 V
Power consumption (standby)	1 W
Power consumption (typical)	22 W
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	120 mm
Width	110 mm
Height	174 mm
Weight	4200 g
