Panasonic SC-ALL2 User Manual

- 30 -
Bluetooth
®
operations
By using the Bluetooth
®
connection, you can listen to the sound of the
Bluetooth
®
audio device wirelessly.
≥ Refer to the operating instructions of the Bluetooth
®
device for further
instruction on how to connect a Bluetooth
®
device.
Preparation
≥ Turn on the Bluetooth
®
feature of the device and place the device near
this unit.
∫ Bluetooth
®
pairing
1 Touch [ ].
≥ If [ ] blinks fast, go to step 3.
2 To enter pairing mode, touch and hold [ ] for at least
2 seconds.
≥ [ ] will blink fast.
3 Select “SC-ALL2” from the Bluetooth
®
device’s Bluetooth
®
menu.
≥ The MAC address (e.g., 6C:5A:B5:B3:1D:0F) may be displayed before
“SC-ALL2” is displayed.
≥ [ ] lights up and the device is connected to this unit.
Connecting via Bluetooth
®
menu

Panasonic SC-ALL2 Specifications

General

Speaker type	1-way
Tweeter diameter	80 mm
Number of speakers	1
Audio output channels	1.0 channels
Impedance	- Ω
Frequency range	- Hz
RMS rated power	40 W
Headphone out	Yes
Connectivity technology	Wired & Wireless
Product type	Mono portable speaker
Product color	Black
Recommended usage	Universal
Audio formats supported	AAC, FLAC, MP3, WAV
Power source type	AC
AC adapter frequency	50/60 Hz
AC adapter input voltage	100 - 240 V
Power consumption (standby)	1 W
Power consumption (typical)	22 W
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	120 mm
Width	110 mm
Height	174 mm
Weight	4200 g
