Panasonic SC-ALL2 User Manual

- 36 -
Rear surround
If you have a compatible Panasonic Home Theater Audio System (e.g.
SC-ALL70T/SC-ALL30T), you can use two SC-ALL2 units as rear
surround speakers to enjoy surround speaker sound.
≥ Refer to the operating instructions for your compatible Panasonic Home
Theater Audio System.
Preparation
≥ Turn SC-ALL2 and SC-ALL70T/SC-ALL30T on.
1 Start the pairing mode on SC-ALL70T/SC-ALL30T.
2 Touch and hold [AUX] and [6] on each SC-ALL2 for at least
4 seconds.
≥ The network indicator goes off.
≥ [NET] starts to blink slowly.
3 Touch and hold [AUX] for at least 4 seconds.
≥ The below display is indicated.
4 Make the left and right surround speaker settings on each SC-ALL2.
To set SC-ALL2 as left surround speaker
Touch [VOL –] to select “0-: ”, and then touch [DISP] to confirm.
To set SC-ALL2 as right surround speaker
Touch [VOL +] to select “:-0”, and then touch [DISP] to confirm.
When you have finished the speaker selections, SC-ALL2 will
enter pairing mode.
≥ “0000” blinks on the display.
– When pairing is successful, “good” appears on the display.
– If you try to set left and right surround speakers to the same channel on
SC-ALL2, pairing fails.
– If pairing fails, “FAIL” is displayed.
Repeat the procedure from the beginning if this occurs.
Pairing
Blinking

Panasonic SC-ALL2 Specifications

General

Speaker type	1-way
Tweeter diameter	80 mm
Number of speakers	1
Audio output channels	1.0 channels
Impedance	- Ω
Frequency range	- Hz
RMS rated power	40 W
Headphone out	Yes
Connectivity technology	Wired & Wireless
Product type	Mono portable speaker
Product color	Black
Recommended usage	Universal
Audio formats supported	AAC, FLAC, MP3, WAV
Power source type	AC
AC adapter frequency	50/60 Hz
AC adapter input voltage	100 - 240 V
Power consumption (standby)	1 W
Power consumption (typical)	22 W
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	120 mm
Width	110 mm
Height	174 mm
Weight	4200 g
