Panasonic SC-ALL2 User Manual

- 22 -
The following steps are based on “Panasonic Music Streaming”.
1 Turn this unit on.
≥ Check that the network indicator (blue) lights up.
– If the network indicator is blinking in blue and red, wait until the blinking
stops.
2 Start the app “Panasonic Music Streaming”.
≥ Always use the latest version of the app.
3 Select a music source.
≥ To add music source, select “+ My Music Network” and then select the
device containing music.
– The added music source is numbered in order from 1.
4 Select a song.
5 From “Select Speaker”, select this
system as the output speakers.
≥ If you have multiple speakers powered by
AllPlay, you can enjoy synchronised
sound from them. Select “ ” and then
select the speakers to group.
– You can change the speaker mode setting for SC-ALL2 to left or right
channel to make stereo pairing.
– You can also play different songs on other speakers powered by AllPlay at
the same time.
– The number of speakers powered by AllPlay that can perform playback at
the same time differs depending on the situation of use.
– When you turn off one of the speakers powered by AllPlay, other
speakers in the same group may stop the playback.
∫ Enhancing the sound
When using the app “Panasonic Music Streaming”, you can use the below
sound functions from the settings of the app.
≥ Equaliser
≥ Clear mode dialog
My room
e.g.,

Panasonic SC-ALL2 Specifications

General

Speaker type	1-way
Tweeter diameter	80 mm
Number of speakers	1
Audio output channels	1.0 channels
Impedance	- Ω
Frequency range	- Hz
RMS rated power	40 W
Headphone out	Yes
Connectivity technology	Wired & Wireless
Product type	Mono portable speaker
Product color	Black
Recommended usage	Universal
Audio formats supported	AAC, FLAC, MP3, WAV
Power source type	AC
AC adapter frequency	50/60 Hz
AC adapter input voltage	100 - 240 V
Power consumption (standby)	1 W
Power consumption (typical)	22 W
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	120 mm
Width	110 mm
Height	174 mm
Weight	4200 g
