Panasonic SC-ALL2 User Manual

- 19 -
1 Disconnect the AC mains lead.
2 Connect this unit to a broadband router, etc. using a LAN cable.
3 Connect the AC mains lead to this unit, and turn the unit on.
≥ When the connection is established, the network indicator (blue) lights up.

≥ Use category 5 or above straight LAN cables (STP) when connecting to
peripheral devices.
≥ The LAN cable must be connected or disconnected while the AC mains lead is
disconnected.
≥ Inserting any cable other than a LAN cable in the LAN port can damage the
unit.
≥ If the LAN cable is disconnected, the network-related settings (l 20) will be
initialized. In that case, make the settings again.
≥ When a LAN cable is connected, the Wi-Fi function will be disabled.
– Power consumption will be reduced when the unit is turned on or is in
standby mode.
Using a LAN cable
Broadband router, etc.
e.g.,
LAN cable (not supplied)

Panasonic SC-ALL2 Specifications

General

Speaker type	1-way
Tweeter diameter	80 mm
Number of speakers	1
Audio output channels	1.0 channels
Impedance	- Ω
Frequency range	- Hz
RMS rated power	40 W
Headphone out	Yes
Connectivity technology	Wired & Wireless
Product type	Mono portable speaker
Product color	Black
Recommended usage	Universal
Audio formats supported	AAC, FLAC, MP3, WAV
Power source type	AC
AC adapter frequency	50/60 Hz
AC adapter input voltage	100 - 240 V
Power consumption (standby)	1 W
Power consumption (typical)	22 W
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	120 mm
Width	110 mm
Height	174 mm
Weight	4200 g
